AMD Radeon R9 M390
AMD Radeon R9 M390, 2015 yılına ait hızlı orta sınıf mobil grafik kartı. Eski Pitcairn çipi tabanlı olup 958 Mhz saat hızına sahip 2014 shader çekirdeği ile gelmekte. Ek olarak 2 GB GDDR5 harici grafik belleği 256 Bit bellek arayüzü ile bağlanmakta. Grafik kartı Apple iMac 27 inç modellerinde kullanılıyor.
Grafik kartının performansı Nvidia GeForce GTX960M veya 870M modellerinden biraz daha iyi ancak Radeon R7 370 masaüstü modelinin çok daha ötesinde. Bu sayede 2015 yılına ait oyunlar Full HD çözünürlüklere kadar oynanabilir.
| Üretici | AMD |
| Radeon R9 M300 Seri | | Radeon R9 M395X | 2048 @ 909 (Boost) MHz | 256 Bit @ 5460 MHz | | Radeon R9 M390X | 2048 @ 723 (Boost) MHz | 256 Bit @ 5000 MHz | | Radeon R9 M395 | 1792 @ 834 MHz | 256 Bit @ 5460 MHz | | Radeon R9 M390 | 1024 @ 958 (Boost) MHz | 256 Bit @ 5460 MHz | | Radeon R9 M385X | 896 @ 1100 MHz | 128 Bit @ 6000 MHz | | Radeon R9 M385 | | 128 Bit @ 6000 MHz | | Radeon R9 M380 | 768 @ 1000 MHz | 128 Bit @ 6000 MHz | | Radeon R9 M370X | 640 @ 800 MHz | 128 Bit @ 4500 MHz | | Radeon R9 M365X | 640 @ 900 - 925 (Boost) MHz | 128 Bit @ 4500 MHz | | Radeon R9 M375 | 640 @ 1015 MHz | 128 Bit @ 2200 MHz |
|
| Kod adı | Pitcairn |
| Mimari | GCN |
| Pipelines | 1024 - birleştirilmiş |
| Çekirdek Hızı | 958 (Boost) MHz |
| Bellek Hızı | 5460 MHz |
| Memory Bus genişliği | 256 Bit |
| Bellek türü | GDDR5 |
| Max. Belek Boyutu | 2048 MB |
| Paylaşımlı bellek | hayır |
| DirectX | DirectX 12 (FL 11_2), Shader 5.0 |
| Transistör sayısı | 5000 milyon |
| teknoloji | 28 nm |
| Özellikler | DirectX 12, OpenCL, DirectCompute 5.0 |
| Notebook Boyutu | geniş |
| Duyurulma Tarihi | 09.06.2015 |
benchmarklar
3DMark 11 - Performance 1280x720
6838 points (22%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | | 6838 |
...
NVIDIA GeForce GTX 775M -11%
AMD Radeon HD 7870 -9%
NVIDIA Quadro P1000 -6%
NVIDIA Quadro P620 -3%
AMD Radeon R9 M390
AMD Radeon Pro 460 2%
AMD Radeon RX 560 (Laptop) 4%
AMD Radeon RX 480 (Laptop) 5%
NVIDIA GeForce GTX 1050 Max-Q 6%
...
NVIDIA Titan RTX 328%
3DMark 11 - Performance GPU 1280x720
6819 points (13%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | | 6819 |
...
NVIDIA GeForce GTX 775M -11%
AMD Radeon HD 7870 -9%
AMD Radeon Pro 460 -1%
AMD Radeon R9 M390
NVIDIA GeForce GTX 1050 Max-Q 4%
AMD Radeon Pro 560X 11%
...
NVIDIA Titan RTX 537%
3DMark 06 Standard 1280x1024 +25800 Points (55%)
| Standard 1280x1024 |
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | | 25800 |
...
NVIDIA GeForce GTX 590 -3%
AMD Radeon R9 M390
AMD Radeon Pro 455 0%
AMD Radeon Pro 555 2%
...
NVIDIA GeForce RTX 2070 (Desktop) 81%
SPECviewperf 12
Solidworks (sw-03) 1900x1060 +SPECviewperf 12 - Solidworks (sw-03) 1900x1060
52.3 fps (25%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | 12.0 | 52.3 |
...
NVIDIA GeForce GTX 1060 (Desktop) -12%
AMD Radeon Pro 455 -9%
AMD Radeon Pro 555 -7%
AMD Radeon R9 M390
NVIDIA Quadro M600M 0%
NVIDIA GeForce GTX 1660 Ti (Desktop) 6%
AMD Radeon RX 580 (Laptop) 6%
NVIDIA GeForce RTX 2060 (Desktop) 10%
NVIDIA GeForce RTX 2060 Super 13%
...
NVIDIA Quadro P5200 294%
Siemens NX (snx-02) 1900x1060 +SPECviewperf 12 - Siemens NX (snx-02) 1900x1060
15 fps (6%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | 12.0 | 15 |
...
NVIDIA GeForce RTX 2070 Super -24%
NVIDIA GeForce RTX 2080 (Desktop) -21%
NVIDIA GeForce RTX 2080 Super -18%
AMD Radeon Pro 455 -7%
AMD Radeon Pro 555 -5%
AMD Radeon R9 M390
AMD Radeon Pro WX 3100 Mobile 10%
AMD Radeon RX 580 (Laptop) 11%
NVIDIA Quadro K620M 14%
AMD FirePro W2100 17%
AMD Radeon RX 570 (Desktop) 29%
AMD Radeon Pro Vega 20 30%
...
NVIDIA Titan RTX 1609%
Showcase (showcase-01) 1900x1060 +SPECviewperf 12 - Showcase (showcase-01) 1900x1060
32.8 fps (17%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | 12.0 | 32.8 |
...
NVIDIA Quadro P1000 -16%
NVIDIA Quadro P2000 Max-Q -9%
NVIDIA Quadro P2000 -7%
NVIDIA GeForce GTX 1050 Ti (Laptop) 6%
AMD FirePro W7170M 13%
AMD Radeon Pro WX Vega M GL 17%
...
NVIDIA Titan RTX 484%
Medical (medical-01) 1900x1060 +SPECviewperf 12 - Medical (medical-01) 1900x1060
6.7 fps (8%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | 12.0 | 6.7 |
...
AMD FirePro W4100 -26%
AMD FirePro W4190M -21%
NVIDIA GeForce 930MX -14%
AMD FirePro W4170M -13%
AMD FirePro W5130M -12%
NVIDIA Quadro K620M 5%
NVIDIA Quadro M600M 12%
...
NVIDIA Titan RTX 1199%
Maya (maya-04) 1900x1060 +SPECviewperf 12 - Maya (maya-04) 1900x1060
31.1 fps (16%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | 12.0 | 31.1 |
...
AMD Radeon Pro 455 -3%
AMD Radeon Pro 555 -2%
AMD Radeon RX 570 (Desktop) 2%
NVIDIA Quadro P600 20%
...
Energy (energy-01) 1900x1060 +SPECviewperf 12 - Energy (energy-01) 1900x1060
0.3 fps (1%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | 12.0 | 0.27 |
...
AMD Radeon Pro 455 -30%
AMD FirePro W2100 -7%
AMD Radeon R9 M390
AMD Radeon R7 M275DX 4%
AMD Radeon Pro WX 3100 Mobile 7%
NVIDIA GeForce 930MX 11%
AMD Radeon Pro 555 19%
Intel UHD Graphics 630 19%
...
NVIDIA Titan RTX 10315%
Creo (creo-01) 1900x1060 +SPECviewperf 12 - Creo (creo-01) 1900x1060
33.1 fps (21%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | 12.0 | 33.1 |
...
NVIDIA Quadro P500 -21%
NVIDIA GeForce GTX 1650 (Desktop) -17%
NVIDIA Quadro M600M -4%
AMD Radeon Pro 455 -1%
AMD Radeon R9 M390
NVIDIA GeForce GTX 1070 SLI (Desktop) 1%
AMD Radeon Pro 555 1%
NVIDIA GeForce GTX 1060 (Desktop) 7%
...
NVIDIA Quadro P5200 371%
Catia (catia-04) 1900x1060 +SPECviewperf 12 - Catia (catia-04) 1900x1060
49.8 fps (25%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | 12.0 | 49.8 |
...
NVIDIA Quadro P600 -20%
NVIDIA GeForce GTX 1650 (Desktop) -14%
NVIDIA GeForce GTX 1060 (Desktop) 3%
NVIDIA Quadro P620 9%
NVIDIA Quadro P1000 9%
AMD Radeon RX 570 (Desktop) 10%
AMD FirePro W7170M 16%
...
NVIDIA Quadro P5200 287%
Cinebench R10 Shading 32Bit +Cinebench R10 - Shading 32Bit
12092 Points (61%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | | 12092 |
...
AMD Radeon HD 6870 -10%
AMD Radeon HD 7870 -8%
Intel Iris Pro Graphics 580 -6%
NVIDIA GeForce RTX 2080 (Laptop) -4%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -3%
AMD Radeon R9 M390
AMD Radeon Pro Vega 20 1%
NVIDIA Quadro P4000 Max-Q 3%
AMD Radeon Pro 455 5%
AMD Radeon RX Vega M GH 8%
NVIDIA Quadro P600 9%
AMD Radeon Pro 460 12%
NVIDIA GeForce RTX 2070 (Laptop) 21%
AMD Radeon RX Vega 64 30%
...
NVIDIA GeForce RTX 2070 (Laptop) 21%
Cinebench R11.5 OpenGL 64Bit +Cinebench R11.5 - OpenGL 64Bit
93.6 Points (55%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | | 93.6 |
AMD FirePro W7170M -8%
AMD Radeon RX 580 (Laptop) -7%
NVIDIA Quadro M4000M -5%
NVIDIA Quadro P4000 Max-Q -4%
AMD Radeon R9 M390
AMD Radeon Pro Vega 20 3%
NVIDIA Quadro P2000 Max-Q 7%
AMD Radeon Pro 460 10%
...
NVIDIA Quadro P5200 69%
Cinebench R15
OpenGL 64Bit +Cinebench R15 - OpenGL 64Bit
min: 91 avg: 101.6 median: 101 (41%) max: 112 Points
NVIDIA GeForce GTX 1050 Max-Q -4%
AMD Radeon Pro 560X -3%
AMD Radeon RX 560 (Laptop) -3%
NVIDIA GeForce GTX 1050 Ti (Laptop) -2%
AMD Radeon Pro 455 -2%
AMD FirePro W7170M 1%
NVIDIA GeForce GTX 1650 (Laptop) 3%
NVIDIA Quadro P4000 Max-Q 3%
NVIDIA GeForce GTX 1050 Ti Max-Q 4%
NVIDIA Quadro P4000 6%
...
NVIDIA Quadro RTX 4000 Max-Q 126%
Ref. Match 64Bit +Cinebench R15 - Ref. Match 64Bit
min: 98 avg: 98.8 median: 98 (98%) max: 99 Points
...
AMD Radeon RX 550X (Laptop) -1%
Intel HD Graphics (Cherry Trail) -1%
Intel Iris Plus Graphics 640 -1%
Intel UHD Graphics 617 1%
Intel Iris Plus Graphics 650 1%
AMD Radeon Pro Vega 56 1%
AMD Radeon Pro 450 1%
AMD Radeon Pro 555 1%
AMD Radeon Pro 560X 1%
...
NVIDIA Quadro T1000 (Laptop) 1%
LuxMark v2.0 64Bit - Room GPUs-only
711 Samples/s (13%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | | 711 |
...
AMD Radeon Pro 460 -13%
NVIDIA GeForce MX250 -12%
NVIDIA Quadro P600 -11%
AMD Radeon Pro 560 -4%
AMD Radeon R9 M390
AMD Radeon R9 M280X 3%
NVIDIA Quadro P1000 3%
AMD Radeon R9 M385X 3%
AMD FirePro W7170M 10%
...
LuxMark v2.0 64Bit - Sala GPUs-only
1287 Samples/s (12%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | | 1287 |
...
NVIDIA Quadro P600 -11%
NVIDIA GeForce MX250 -9%
AMD Radeon Pro 460 -7%
AMD Radeon R9 M390
NVIDIA Quadro P1000 1%
AMD Radeon R9 M280X 3%
AMD Radeon Pro 560 3%
AMD Radeon R9 M385X 3%
AMD FirePro W7170M 10%
...
NVIDIA Titan RTX 739%
ComputeMark v2.1 - Normal, Score 1024x600
4417 Points (16%)
| Apple iMac Retina 5K 27 Late 2015 3.2 GHz M390 MK472D/A | 6500 | 8192 MB | | | 4417 |
...
AMD Radeon RX 560X (Laptop) -22%
NVIDIA Quadro P1000 -20%
AMD Radeon R9 M385X -19%
AMD Radeon Pro 560 -15%
AMD Radeon Pro 460 -13%
NVIDIA GeForce GTX 1050 Ti (Laptop) 0%
AMD Radeon R9 M390
NVIDIA GeForce GTX 1050 Max-Q 1%
NVIDIA Quadro M3000M 7%
NVIDIA Quadro P2000 10%
NVIDIA GeForce GTX 1050 Ti Max-Q 10%
...
NVIDIA Titan RTX 532%
- Bu grafik kartı için benchmark aralıkları
- Bu grafik kartı için ortalama benchmark değerleri
* Smaller numbers mean a higher performance
Oyun Benchmarkları
Aşağıdaki testler laptop incelemelerimizden ortaya çıkmaktadır. Performans kullanılan grafik kartı belleğine, saat hızına, işlemci, sistem ayarları, sürücüler ve işletim sistemine göre değişir. Bu yüzden sonuçların bu grafik kartına sahip tüm laptopları karşılaması beklenmemelidir.
NVIDIA Quadro P4000 -24%
NVIDIA Titan X Pascal 5%
...
NVIDIA GeForce GTX 1080 (Desktop) 24%
Intel HD Graphics (Cherry Trail) -96%
...
NVIDIA Quadro P4000 9%
NVIDIA Quadro M3000M 16%
...
NVIDIA GeForce GTX 1080 (Desktop) 87%
NVIDIA Quadro M3000M 10%
...
NVIDIA GeForce 910M -91%
...
AMD Radeon R9 M280X -57%
NVIDIA Quadro M3000M 12%
...
...
NVIDIA Quadro M3000M 19%
...
» test edilen tüm laptoplarda ultra detaylarında oynanabilir.
...
AMD Radeon RX 580 (Laptop) -4%
...
NVIDIA Titan X Pascal 142%
...
NVIDIA GeForce 920MX -61%
AMD Radeon RX 580 (Laptop) 20%
...
NVIDIA Titan X Pascal 204%
...
...
NVIDIA Titan X Pascal 335%
» test edilen tüm laptoplarda orta detaylarında oynanabilir.
AMD Radeon R9 M385X -39%
AMD Radeon Pro 450 -37%
AMD Radeon Pro 455 -28%
AMD Radeon HD 7870 16%
AMD Radeon Pro WX Vega M GL 29%
...
AMD Radeon R5 M330 -86%
...
AMD Radeon R9 M280X -48%
AMD Radeon R9 M385X -36%
AMD Radeon Pro WX Vega M GL 17%
AMD Radeon HD 7870 18%
...
...
NVIDIA Quadro P2000 -6%
AMD Radeon Pro WX Vega M GL 7%
NVIDIA GeForce GTX 1050 Ti (Laptop) 34%
...
» test edilen tüm laptoplarda yüksek detaylarında oynanabilir.
NVIDIA Quadro P4000 Max-Q 18%
...
NVIDIA GeForce GTX 1060 (Desktop) 54%
...
AMD Radeon R9 M280X -57%
AMD Radeon R9 M385X -53%
...
NVIDIA GeForce GTX 1060 (Desktop) 113%
...
AMD Radeon R9 M385X -48%
AMD Radeon R9 M280X -43%
...
AMD Radeon R5 M335 -79%
...
AMD Radeon R9 M280X -31%
...
...
...
» test edilen tüm laptoplarda yüksek detaylarında oynanabilir.
AMD Radeon Pro 455 -17%
AMD Radeon Pro 450 -16%
AMD Radeon RX 580 (Laptop) -4%
NVIDIA Titan X Pascal 9%
AMD Radeon Pro 460 17%
...
...
AMD Radeon R9 M385X -23%
AMD Radeon Pro 460 -18%
AMD FirePro W7170M 37%
...
NVIDIA GeForce GTX 1080 (Desktop) 379%
...
AMD Radeon Pro 455 -36%
AMD Radeon Pro 460 -27%
AMD Radeon R9 M385X -17%
...
NVIDIA Titan X Pascal 533%
AMD FirePro W2100 -83%
...
AMD FirePro W2100 -83%
AMD FirePro W4100 -75%
...
NVIDIA Titan X Pascal 634%
» test edilen tüm laptoplarda düşük detaylarında oynanabilir.
...
NVIDIA GeForce GTX 1060 (Desktop) 68%
...
AMD Radeon R9 M280X -64%
...
NVIDIA GeForce GTX 1060 (Desktop) 79%
...
AMD Radeon R9 M280X -52%
AMD Radeon R9 M385X -47%
...
...
AMD Radeon R9 M280X -64%
...
NVIDIA Titan X Pascal 402%
» test edilen tüm laptoplarda ultra detaylarında oynanabilir.
AMD Radeon HD 6450 GDDR5 -89%
...
AMD Radeon Pro 450 -40%
NVIDIA GeForce MX250 -35%
AMD Radeon Pro 455 -28%
AMD Radeon Pro 560X -9%
AMD Radeon RX 560X (Laptop) -4%
NVIDIA GeForce GTX 1650 (Laptop) 14%
...
...
AMD Radeon RX Vega 8 -45%
AMD Radeon R9 M280X -32%
AMD Radeon Pro 560X -9%
NVIDIA GeForce GTX 1050 Ti Max-Q 43%
...
» test edilen tüm laptoplarda ultra detaylarında oynanabilir.
...
AMD Radeon RX Vega 8 0%
Intel Iris Pro Graphics 580 0%
...
Intel UHD Graphics 630 0%
...
...
...
...
...
AMD Radeon RX Vega 8 -55%
AMD Radeon R9 M280X -46%
AMD Radeon R9 M385X -36%
AMD Radeon Pro WX Vega M GL 26%
AMD Radeon RX Vega M GH 49%
...
...
NVIDIA Quadro P2000 16%
AMD Radeon Pro WX Vega M GL 16%
NVIDIA Quadro P2000 Max-Q 30%
<
